This is an unflown AGM-86A, the first version of the U.S. Air Force's air-launched cruise missile (ALCM). Designed to carry either a conventional or nuclear warhead, it had a turbofan jet engine, flew at subsonic speeds, had a range of 1,125 kilometers (700 miles), and used an inertial navigation system with terrain-contour matching radar. Because the missile flew close to the ground, it was difficult for enemy radars to detect. Most AGM-86As were used in flight tests in 1976, and none became operational. Subsequent versions of the ALCM with conventional or nuclear warheads and a longer range have been produced and deployed on B-1 and B-52 bombers. Made by Boeing, this artifact was donated by the U.S. Air Force to NASM in 1978.

 Display Status

This object is on display in Rockets & Missiles at the Steven F. Udvar-Hazy Center in Chantilly, VA.

Rockets & Missiles
Object Details
Country of Origin United States of America Type CRAFT-Missiles & Rockets Manufacturer Boeing Aerospace Company
 Physical Description Long-range, subsonic, winged missile designed to be air-launched from B-52 or B-1 bombers. Dimensions Overall: 14 ft. x 9 ft. 6 in. span (426.72 x 289.56cm)
 Materials Aluminum
 Alternate Name AGM-86A Cruise Missile Inventory Number A19781809000 Credit Line Transferred from the United States Air Force. Data Source National Air and Space Museum Restrictions & Rights Usage conditions apply
