Following rendezvous with the Lunar Module after its ascent from the lunar surface, the LM Active Docking Target, made by Symbolic Displays Inc., is mounted in the Command Module Rendezvous window inside the spacecraft to serve as an aid to the LM pilot in making his final approach for docking. The target has a standoff cross and is illuminated using power from the Command Module electrical system. When not in use the Docking Target is stowed in one of the Command Module lockers.
This docking target was used during the historic Apollo 11 lunar landing mission inside the Command Module "Columbia." NASA transferred it to the Smithsonian in 1970.
Display Status
This object is not on display at the National Air and Space Museum. It is either on loan or in storage.
Object Details
Date
1968
Country of Origin
United States of America
Type
SPACECRAFT-Crewed-Parts & Structural Components
Manufacturer
Symbolic Displays Inc.
Dimensions
3-D: 19.7 × 21cm (7 3/4 × 8 1/4 in.)
Materials
Overall: metal and plastic
Inventory Number
A19980056000
Credit Line
Transferred from NASA/JSC; must be offered back to NASA upon deaccession
Data Source
National Air and Space Museum
Restrictions & Rights
Usage conditions apply
